Low power consumption

7.5mA when TX at +4dBm output power.

NFC touch to pair

Also with hardware divider, FPU and DAC

5.0

Bluetooth

Increase speed and reliability of data transfer between BLE devices. Specifically for IoT application.

Built-in Antenna

The antenna is built on SiP package.
No extra space is needed for your design.

Audio

Capable for digital microphone and voice input speech recognition control.

Bluetooth Mesh

The addition of mesh networking capabilities to Bluetooth Low Energy enables extended range, increases the number of nodes and a many-to-many (m:m) communication topology.

Feature List

  • Multi-protocol with Bluetooth low energy / ANT / 2.4G RF
  • Built-in antenna
  • 32-bit ARM® Cortex™-M4F processor
  • 512kB flash + 64kB RAM
  • LGA-52 package, 6.5 ✕ 6.5 x 1.1 mm
  • Application development independent from protocol stack
  • Programmable output power from +4dBm to -20dBm
  • Flexible and configurable 26 pin GPIO
  • Simple ON/OFF global power modes
  • Digital interfaces including: SPI/2-wire/UART/PDM/I²S
  • 12-bit/200KSPS ADC
  • 128-bit AES ECB/CCM/AAR co-processor
  • NFC touch-to-pair
  • Quadrature demodulator
  • Low power 32MHz crystal inside the module
  • Ultra-low power 32kHz crystal and RC oscillators for best power consumption
  • Wide supply voltage range (1.7 V to 3.6 V)
  • On-chip DC/DC buck converter
  • Individual power management for all peripherals
  • FCC, CE and BQB certification (under going)

Applications

IoT

  • Smart home
  • Sensor networks
  • Building automation
  • Industrial
  • Retail

Personal area networks

  • Health/fitness sensor and monitor devices
  • Medical devices
  • Key-fobs and wrist watches

Interactive entertainment devices

  • Remote controls
  • Gaming controllers

Computer peripherals and I/O devices

  • Mouse
  • Keyboard
  • Multi-Touch-PAD

Beacons

A4WP wireless chargers and devices

Remote control toys

MtConnect05 Kit


Get now

Documentation

  • Datasheet PDF

Reference Design

  • Library for Altium Designer 16 ZIP

Pre-Test & Certification

M905

CE

  • EN 300 328 Radio Test Report PDF
  • EN 300 330 Radio Test Report PDF
  • EN 301 489-1 489-3 EMC Test Report PDF
  • EN 301 489-1 489-17 EMC Test Report PDF
  • EN 60950 Test Report PDF
  • EN 62479 Test Report PDF

FCC

  • Part 15 247 Radio Test Report PDF
  • FCC Grant PDF
  • FCCID: 2AJ9P-M905
